Product Attribute	Attribute Value
Approvals	CSA C22.2 No.14, UL508
Connection Type	Pin Terminal
Depth	0.157" (4mm)
Dimensions, Cutout, Inches	45 x 45 mm
Display Digit Height	10 mm
Display Type	Digital, LCD
Function	Timer
Input Type	Contact Open, Short-Circuit
Measuring Range	0.1 to 999.9 sec.
Minimum Operating Temperature	-10 °C
Mounting Type	Flush, Surface
Number of Digits	4 Digits
Output Type	SPDT
Series
Supply Voltage	100 to 240, 12 to 48 VAC, VDC VAC, VDC
Temperature Range	-10 to 55 °C
Temperature, Opening, Maximum	55 °C
Termination	Pin
Type	Electronic
