| Product Attribute | Attribute Value |
|---|---|
| Accuracy | ±0.01% % |
| Connection Type | Cage-Clamp |
| Cut Out, Panel | 1⁄8 DIN |
| Depth | 1.95" (49.5mm) |
| Dimensions | 4.2 x 3.8 x 1.95 in. |
| Display Digit Height | 0.56 " |
| Display Resolution | 0.001 Sec. (Minimum Digit), 1 hr. (Single Digit) |
| Display Type | LED |
| Function | Timer |
| Humidity | 0 to 85% (Max.) RH |
| Isolation Voltage | 2300 V (RMS) |
| Length | 4.2" (106.68mm) |
| Maximum Operating Temperature | 50 °C |
| Measurement Range | 0 to 999999 |
| Memory Type | Non-Volatile EEPROM |
| Minimum Operating Temperature | 0 °C |
| Mounting Style | Panel Mount |
| Number of Digits | 6 Digits |
| Operating Temperature | 0 to 50 °C |
| Power Rating | 18 VA |
| Primary Type | Electronic |
| Product Header | PAX 1/8 DIN 6 Digit Timer/Real Time Clock |
| Series | |
| Special Features | Programmable Function Keys |
| Standards | cULus Listed, CSA Certified, NEMA 4X, IP65 |
| Stripping Length | 0.3 in. Wire |
| Supply Voltage | 85 to 250 VAC |
| Temperature Operating Range | 0 to 50 °C |
| Terminal Type | Cage Clamp |
| Termination | Cage Clamp |
| Torque | 4.5 in.-lbs |
| Type | Clock/Timer |
| Voltage Range | 85 to 250 VAC |
| Width | 3.8" (96.5mm) |
Overview
The PAX TM/CK offer many features and performance capabilities to suit a wide range of industrial applications. Both can function as an elapsed timer, or preset timer, while the PAXCK also offers real-time clock and date capabilities. By using two separate signal inputs and 23 selectable timer ranges, the meters can be programmed to meet most any timing application. With the addition of a plug-in set-point card, they easily become a dual- or quad-output preset timer.
